DESCRIPTION

B737-800 freighter has the capacity for 12 pallet positions that can accommodate 11 standard 88in x 125in pallets and one 88in x 62in contoured pallet. The aircraft has a length of 39.5m, a wingspan of 35.8m and height of 12.6m. Its maximum take-off weight (MTOW) is 79,000kg, while the maximum landing weight is 66,350kg.

The 737-800BCF is capable of transporting up to 23.9t of cargo. The volume limit payload capacity of the aircraft is 20.76t. The main deck offers 141.5m³ of cargo space, while the lower deck provides 43.7m³ of space for bulk cargo.

Standard 88" x 125"

ULD Common DesignationMax External Dimensions L x W x H (in/cm)Internal Cubic Capacity (ft3 /m3Maximum Gross Weight (lb/kg)Weight Tare (approx) (lb/kg)
A-288 x 125 x 82 in 223 x 317.5 x 208 cm440 ft3 12.5 m313,300 lb 6,033 kg476 lb 216 kg
AM96 x 125 x 82 in 243.84 x 317.5 x 208.28 cm623 ft3 17.6 m315,000 lb 6,803 kg630 lb 286 kg
PB (463L)88 x 108 x 82 in 244 x 274.3 x 208.28 cm380 ft3 10.7 m310,000 lb 4,535 kg185 lb 84 kg
AKE60.4 x 79.0 x 64.0 in 153.4 x 200.6 x 162.56 cm153 ft3 4.3 m33,500 lb 1,588 kg191 lb 87 kg
PKC61.5 x 60.4 x 71.0 in 156.2 x 153.4 x 180.34 cm153 ft3 4.3 m33,500 lb 1,588 kg154 lb 70 kg

WEIGHT & PAYLOAD LIMITATIONS

Maximum Revenue Payload

Main Cargo Compartment

Lower Forward/Aft Compartment (Bulk)

Maximum Design Range

Maximum Gross Takeoff Weight

Maximum Gross Landing Weight

52,800 lb / 23,950 kg

4,993 ft3 / 141.4 m3

1,543 ft3 / 43.7 m3

2,609 nm / 4,830 km

174,000 lb / 79,000 kg

146,300 lb / 66,350 kg
